Box Profile Steel Cladding Sheets - 0.5mm

Box profile steel roofing sheets are available in a range of different finishes & lengths.

Quickest Available Delivery: Quickest Available Delivery: 5 Day Delivery Final shipping costs and times are calculated at checkout. Shipping address may affect available delivery methods & times.

Box Profile cladding sheets offer an alternative to the traditional corrugated steel cladding sheets. They are called box profiled because of the shape that the sheet takes on once it is rolled, with a series of profiles and valleys. They are especially designed so that the rain water runs off the high peak steel profiles on the cladding & into the valleys, which then run the water off the sheets.

As standard our box profile cladding sheets are rolled to a 32/1000 specification. This means that the coverage of the cladding sheet is 1000mm (1 meter) once they are lapped and fitted. It also means that the depth of the profile from the top of the profile to the bottom of the valleys is 32mm.

Although we stock the sizes shown on this page, we can also manufacture box profile steel cladding sheets at any length you require, up to 10 meters in length. Most commonly box profile cladding sheets are used as a single skin sheeting system, form part of a double skin insulated cladding system or to overclad an existing building.
