Erosion Control Geomat
Frequently Bought Together
This range of Geomats provides you with a three-dimensional synthetic erosion control solution for permanent reinforcement to the grass-root matrix for permanent surface erosion protection.
Ideal for situations where vegetation requires permanent assistance to protect the ground from weather and water erosion – the densely fused strands will imitate the role of a root matrix to bind and trap soil particles as well as fertile humus to reinforce the soil.
GeoMats also enable the rapid development of vegetation with filaments offering long-term support to the plant root matrix assisting them to resist undermining due to erosion.
GeoMats are typically used on sites where established vegetation cannot resist erosion – this includes riverbanks, drainage channels and steep slopes. The extruded polypropylene monofilament or stitched net construction effectively provide soil reinforcement.
Features:
- Provides long term erosion control
- Tough, flexible fabric
- Promotes vegetation establishment
- Permanent protection
- Allows roots to intertwine and bind to mat
|
Feature |
20Z 500 Mat | 20Z 500 M Mat | 20Z 500 G50 Mat |
|---|---|---|---|
| Thickness | 20 | 18 (+-3) | 20 |
| Tensile Strength MD/CD (kN/m) | 1.35/0.85 | 4.5/5 | 50 |
| Elongation MD/CD (%) | 30/30 | 25/25 | 3 |
| Weight | 500g/m2 | 500g/m2 | 250g/m2 |
| Flow Velocity (m/s) | 2 to 6 | 2 to 6 | 4 to 7 |
| Material | Black, UV Stabilised, Polyethylene | Black, UV Stabilised, Polyethylene | Multi-filament polymer coated glass fibre reinforcing grid |
| Structure | 3D open matrix | 3D open matrix with mesh | 3D open matrix |
| Roll Size | 2.5m x 25m | 2.5m x 25m | 2.5m x 24m |
HERMEQ stock a wide-range of Geotechnics, Geotextiles, Geomembranes & Root Barriers conforming to all required safety specifications and regulations.
